Freetime M3 Smart Projector

Appearance

• Product Type: 2.69 Fully Enclosed Unit
• Dimensions: W130MM * H210MM * T143MM
• Gross Weight: 1.7KG (includes remote control, accessory pack, and packaging)
• Net Weight: 1.3KG
• Power Consumption: Less than 70W

System & Hardware Configuration

Optical Parameters

• Display Technology: LCD
• Light Source: LED
• Color Temperature: 20000K
• Light Source Life: 30000H
• Brightness: 200ANSI ±10%
• Lamp Type: LED
• Physical Resolution: 1280*720/60HZ
• Supported Resolutions: 1080P/4K
• Contrast Ratio: 1000:1
• Projection Size: 40-150 inches
• Aspect Ratio: 16:9
• Optimal Size: 60-90 inches
• Throw Ratio: 1.2
• Uniformity: 80% ±%
• Effective Projection Distance: 1-3M
• Focus Mode: Electric focus, Auto focus
• Keystone Correction: Vertical and horizontal keystone / Auto keystone
• Projection Mode: Ceiling mount / Front projection / Side projection
• Automatic Curtain Call: Supported
• Automatic Obstacle Avoidance: Supported
• Speaker: Built-in BOX speaker 4Ω, 3W (2pin 1.25mm interface)
• Internal Circulation Fan: 12V/0.25A 4500 RPM (2pin 1.25mm interface)

Motherboard Selection

• Motherboard Model: Custom H713
• WiFi Module: Dual-band Wi-Fi 2.4G + 5G

Connector Configuration

• USB Ports: Standard USB2.0*2
• HDMI Port: Standard HDMI2.0*1
• Audio Output Port: Standard 3.5 audio port*1
• Power Port: AC port 100~250V 50/60HZ
• Buttons: 1 power button

Product Highlights

• 1080P Ultra HD: Native 1080P resolution, supports HDR10, high dynamic contrast ratio, rich in detail.
• New Generation Optical System: Self-developed high-sealed optical engine with custom-coated high-transparency all-glass lens for enhanced optical performance.
• Smart Focusing System: Instant auto-focus, eliminating the hassle of manual focusing.
• Automatic Keystone Correction: Supports six-direction correction, automatically adjusting the image to a rectangle regardless of projector placement.

Other Features

• Massive Content Library: Aggregates resources from multiple platforms such as YouTube, Netflix, and Disney+, providing real-time updates for more audiovisual enjoyment.
• Large Sound Chamber Design: Provides an immersive audio experience.
• Wi-Fi 6: Ultimate speed, supporting 2.4G/5GHz dual-band Wi-Fi for smooth gaming and streaming.
• 22dB Silent Operation: Low noise during operation.
• Delicate Colors, Vivid Images: Independently calibrated colors based on the human visual system, enhanced color and contrast, SRGB>120%.
• Multi-Scene Use: Suitable for home theater, private yoga, gaming, and various entertainment experiences.
• Flexible Gimbal: Self-developed new generation gimbal with high-density AL6061 aluminum material, supporting 360° rotation for free projection.
• Wireless Screen Mirroring: Supports wireless screen mirroring for phones, tablets, and laptops, connecting to the same Wi-Fi for shared screens.

Smart Features

• AI Voice Control: Play movies, music, etc., through voice commands, making operation simple.
• Fully Intelligent Adaptive System: Auto-focus, keystone correction, screen alignment, and obstacle avoidance for more convenient use.

Specifications

• Projection Size: 30-100 inches, suitable for home theater, private yoga, and various scenes.
• Lens: Million-pixel lens with hundred-level electronic zoom.
• Display Technology: LCD, LED light source.
• Standard Resolution: 1080P clarity.
• Interfaces: HDMI x1, USB x2, supports Wi-Fi 6 and Bluetooth connectivity.

Warranty

Warranty period allows for replacement if damaged within six months.
